M-VAVE ANNBLACKBOX Multi Effects Processor Rechargeable Guitar Pedal for Electric Guitar Bass

Product Features:
ANNBLACKBOX is a portable and multifunctional Guitar/Bass effector. lt has 80 editable Presets the users also can customize effectors chain and save. It has built-in battery it can last up to 10 hours on a full charge. ANNBLACKBOX has 6 effects Modules it provides the Noise Gate Boost Compressor 20 Preamp 3-band EQ 7 Modulations 5 Delays 6 Reverbs 20 lR CAB slots and so on.
Press the HOME button on the Main Display Screen to enter the Module Operation Screen then use the PARA Knob to customize the position of the effects Module. At this time you can also select any Module by pressing the Right-Footswitch and then open/close this module with the Left-Footswitch which is convenient for the user to control the Module on/off with the foot during the performance(Stomp Mode). When you click the MOD/DLY Button the MOD/DLY Module opens on the screen you can tap the Right-Footswitch to adjust the effect speed of the MOD/DLY Module.
You can download the computer software or mobile APP from our official channels use it to edit presets swap presets share presets import/export presets and import the lR files import the  AMP module timbre data besides you can restore the factory Settings or firmware upgrade on the computer. It support BT wireless music earphone monitoring function and computer sound card etc. ANNBLACKBOX can be used as an audio interface with a cellphone use a OTG converter (separately buying) and accessory USB cable to connect the cellphone then enter any video/audio recording APP for direct recording. It integrates a variety of function it is easy-carry and it has excellent sound! It could be a good partner of your music instruments.

Specifications:

• Input: Standard 1/4″ jack MONO/TS

• Output: Standard 1/4″ jack MONO/TS 1/8″ Stereo jack

• Sample rate: 44.1KHz/24bit

• Size: 113(L)x109(W)x41(H)mm

• weight: 410g

• Power supply & USB data transmit: Type-C 5V≥300mA

• Battery capacity: 2000mah

• Battery Model/Type: 103450

• Battery Nominal Voltage: 3.7V

• Battery life: 10+ hours

• charging current limit: about 408 mA

• Dynamic Range: 105dB

• Total effects: 60+

• Effects Slots/Effects Modules: Total of 6+1 simultaneous effects slots it can customized the order

• Presets amount: 40+40

• USB AUDIO (OTG): 44.1K/24Bit support Loopback ON/OFF

• BT music: support

• Software support: WINDOWS MAC IOS Androind

• lR processing: 44.1K/24Bit Mono WAV files 1024 sampling points

• Power supply: built-in battery or USB 5V

• AMP modeler: totally 20 (1-15 is electric guitar preamp 16-20 for bass preamp)

• IR slots: totally 20 (1-15 is electric guitar CAB 16-20 for bass CAB)

• working current: about 200 mA

  Note:



• The power supply:It is equipped with built-in battery for power supply which can last for 10 hours after full charge. It can charge with the 5V adapter or the power bank. When the battery run low you can use the 5V 2A

  adapter you need 5 hours to fully charge the battery.When the battery run low don’t use it for a long time to avoid unstable working performance please charge it in time.

• The connection:Be sure to turn off the power of related equipment before connecting or disconnecting the device.

• The electrical interference:The electromagnetic wave of radio television and other equipment may cause  interference to the equipment so please try to stay away from radio television and other equipment.

• The location:To avoid deformation discoloration or other serious damage do not expose this unit to the following conditions:

  a. Heat sources

  b. Magnetic fields

  c. Sunlight

  d. High temperature or moist district

  e. Excessively dusty or dirty locations

  f . Strong vibrations or shocks

• Package Includes:
  1 *M-VAVE ANNBlackbox
  1 *USB Cable
